| Model | Output | Discharge | PhaseØ | Start Method | Head | Capacity | Solid Passage mm. | Weight kg. | ||
| HP(kW) | Inch(mm.) | m. | m3/min | m3/h | 1Ø | 3Ø | ||||
| HCP 50AL21.5 | 2 (1.5) | 2” (50) | 1 | Capasitor | 12 | 0.4 | 24 | 20 | 35 | 31 |
| 3 | Direct | |||||||||
| HCP 50AL22.2 | 3 (2.2) | 2” (50) | 1 | Capasitor | 17.5 | 0.4 | 24 | 20 | 38 | 34 |
| 3 | Direct | |||||||||
| HCP 80AL21.5 | 2 (1.5) | 3” (80) | 1 | Capasitor | 8 | 0.6 | 36 | 20 | 37 | 32 |
| 3 | Direct | |||||||||
| HCP 80AL22.2 | 3 (2.2) | 3” (80) | 1 | Capasitor | 12 | 0.6 | 36 | 20 | 39 | 35 |
| 3 | Direct | |||||||||
| HCP 80AL23.7A | 5 (3.7) | 3” (80) | 3 | Direct | 20.5 | 0.6 | 36 | 20 | – | 49 |
| HCP 80(100)AL25.5 | 7.5 (5.5) | 3” (80) | 3 | Direct | 26.5 | 0.6 | 36 | 20 | – | 74 |
| 4” (100) | 20 | 1 | 60 | |||||||
| HCP 80(100)AL27.5 | 10 (7.5) | 3” (80) | 3 | Direct | 34.5 | 0.6 | 36 | 20 | – | 80 |
| 4” (100) | 27 | 1 | 60 | |||||||
| HCP 80(100)AL211 | 15 (11) | 3” (80) | 3 | Star-Delta | 46 | 0.6 | 36 | 20 | – | 90 |
| 4” (100) | 39.5 | 1 | 60 | |||||||
