| Bore | Pump Model | Connection Type | PHASE | Output | Capacity-Total head | Weight (kg) | ||||||
| mm | non-automatic operation | With Automatic Float | Pair Designation | Pump No.1+Pump No.2 | Automatic connection | Flange Connecton | kW | (50Hz) m/min | (60Hz) m/min | CR | CR-D CR-W | |
| 50 | CR501S | CR501DS | CR501DWS | CR501WS+CR501DS | P50RL | F50 | 1 | 0.15 | 0.1-3.4 | 0.1-3.5 | 5.5 | 6 |
| 0.05 | 0.13-4.5 | 0.13-4.8 | 7 | 7.5 | ||||||||
| 3 | 0.4 | 0.16-6.8 | 0.16-6.4 | 8.2 | 8.7 | |||||||
| CR501T | CR501DT | 0.15 | 0.1-3.5 | 0.1-3.5 | 4.9 | 5.4 | ||||||
| 0.02 | 0.13-4.5 | 0.13-4.8 | 6.3 | 6.8 | ||||||||
| 0.4 | 0.16-6.8 | 0.16-6.4 | 7.4 | 7.9 | ||||||||
| CR501 | 0.75 | 0.22-8.8 | 0.22-8.9 | 8.8 | 9.3 | |||||||
| 65 | CR65 | CR501D | P65NR | F65N | 3 | 1.5 | 0.4-9.3 | 0.4-7.9 | 16 | |||
| CR80 | 2.2 | 0.4-12.3 | 0.4-11.3 | 19 | ||||||||
| 80 | CR65 | P80NR | F80N | 3 | 1.5 | .4-9.3 | 0.4-7.9 | 16 | ||||
| CR80 | 2.2 | 0.4-12.3 | 0.4-11.3 | 19 | ||||||||
| Bore | Pump Model | Connection Type | PHASE | Output | Capacity-Total head | Weight (kg) | ||||||
| mm | non-automatic operation | With Automatic Float | Pair Designation | Pump No.1+Pump No.2 | Automatic connection | Flange Connecton | kW | (50Hz) m/min | (60Hz) m/min | CR | CR-D CR-W | |
| 40 | CRC40S | CRC40DS | P40RH | F40 | 1 | 0.4 | 0.05-14.2 | 0.05-14 | 8.9 | 9.4 | ||
| CRC40T | CRC40DT | 3 | 0.05-14.2 | 0.05-14 | 8.8 | 9.3 | ||||||
| 50 | CRC50 | CRC50D | P50RH | F50 | 3 | 0.75 | 0.1-16 | 0.1-17 | 10.2 | 10.7 | ||
| CRC50DW | CRC50W+CRC50D | P50NR | F50N | 1.5 | 0.2-18.2 | 0.2-18.4 | 16 | 16.5 | ||||
| 65 | CRC50 | CRC50D | CRC50DW | CRC50W+CRC50D | P65NR | F65N | 3 | 1.5 | 0.2-18.2 | 0.2-18.4 | 16 | 16.5 |
| CRC65 | CRC65D | CRC65DW | CRC65W+CRC65D | 2.2 | 0.3-20.6 | 0.3-21.3 | 19 | 19.5 | ||||
| 80 | CRC65 | CRC65D | CRC65DW | CRC65W+CRC65D | P80NR | F80N | 3 | 2.2 | 0.3-20.6 | 0.3-21.3 | 19 | 19.5 |
| Bore | Pump Model | Connection Type | PHASE | Output | Capacity-Total head | Weight (kg) | ||||||
| mm | non-automatic operation | With Automatic Float | Pair Designation | Pump No.1+Pump No.2 | Automatic connection | Flange Connecton | kW | (50Hz) m/min | (60Hz) m/min | CR | CR-D CR-W | |
| 32 | CRS321S | CRS321DS | CRS321DWS | CRS321WS+CRD321DS | P32RL | F32 | 1 | 0.15 | 0.15-3.9 | 0.1-3.9 | 5.4 | 5.9 |
| 40 | CRS401S | CRS401DS | CRS401DWS | CRS401WS+CRS401DS | P40RL | F40 | 1 | 0.15 | 0.1-3.9 | 0.1-3.9 | 5.4 | 5.9 |
| 0.25 | 0.13-5.3 | 0.13-5.4 | 6.9 | 7.4 | ||||||||
| CRS401T | CRS401DT | CRS401DWT | CRS401WT+CRS401DT | 3 | 0.15 | 0.1-3.9 | 0.1-3.9 | 4.8 | 5.3 | |||
| 0.25 | 0.13-5.3 | 0.13-5.4 | 6.2 | 6.7 | ||||||||
| 50 | CRS51S | CRS501DS | CRS501DWS | CRS501WS+CRS501DS | P50RL | F50 | 1 | 0.4 | 0.16-7.2 | 0.16-6.8 | 8.1 | 8.6 |
| CRS501T | CRS501DT | CRS501DWT | CRS501WT+CRS501DT | 3 | 0.4 | 0.16-7.2 | 0.16-6.8 | 7.3 | 7.8 | |||
| CRS501 | CRS501D | CRS501DW | CRS501W+CRS501D | 0.75 | 0.22-9.2 | 0.22-9.4 | 8.7 | 9.2 | ||||
| CRS65 | CRS65D | CRS65DW | CRS65W+CRS65D | P50NR | F50N | 3 | 1.5 | 0.4-9.9 | 0.4-7.8 | 16 | 16.5 | |
| 65 | CR65 | CRS65D | CRS65DW | CRS65W+CRS65D | P65NR | F65N | 3 | 1.5 | 0.4-9.9 | 0.4-7.8 | 16 | 16.5 |
| CR80 | CRS80D | CRS80DW | CRS80W+CRS80D | 2.2 | 0.4-13.4 | 0.4-11.8 | 19 | 19.5 | ||||
| 80 | CRS65 | CRS65D | CRS65DW | CRS65W+CRS65D | P80NR | F80N | 3 | 1.5 | 0.4-9.9 | 0.4-7.8 | 16 | 16.5 |
| CRS80 | CRS80D | CRS80DW | CRS80W+CRS80D | 2.2 | 0.4-13.4 | 0.4-11.8 | 19 | 19.5 | ||||
