อื่น ๆ : การระบายน้ำจากท่าเรือและแม่น้ำ
| Model | Output | Discharge | Phase | Start | Head m | Standard | Solid Passage | weight kg | ||
| HP(kW) | Inch(mm) | Ø | Method | m | m3/min | m3/h | mm | 1Ø | 3Ø | |
| HCP L-405A | 0.5(0.4) | 3.5″(90) | 1 | Capacitor | 1.5 | 0.7 | 42 | 10 | 25 | 25 |
| 4″(100) | 3 | Direct | ||||||||
| HCP L-41A | 1(0.75) | 3.5″(90) | 1 | Capacitor | 3 | 0.7 | 42 | 10 | 26 | 26 |
| 4″(100) | 3 | Direct | ||||||||
| HCP L-62A | 2(1.5) | 6″(150) | 3 | Direct | 2 | 2 | 120 | 20 | 26 | 51 |
| HCP L-63A | 3(2.2) | 6″(150) | 3 | Direct | 2.5 | 2 | 120 | 20 | – | 52 |
| HCP L-200A | 7.5(5.5) | 8:(200) | 3 | Direct | 4 | 3.5 | 210 | 22 | – | 116 |
| HCP L-250A | 10(7.5) | 10″(250) | 3 | Direct | 4 | 5.5 | 330 | 22 | – | 157 |
| HCP L-300A | 15(7.5) | 10″(250) | 3 | Direct | 4.5 | 7 | 420 | 23 | – | 201 |
| 12″(300) | ||||||||||
Note Weight*3½”mm
| L Series Large Volume | Standard Specifications | Threaded Outlet Specification | |
| Submersible Pumps | |||
| Model | Specifications | Double Flange Set | |
| HCP L-405A | 0.5HP*3.5″ | L2F4(3.5)-175-180 | 3.5″ Discharge / PF thread |
| 0.5HP*4″ | L2F4-165-190 | 4″ Discharge / PF thread | |
| HCP L-41A | 1HP*3.5″ | L2F4(3.5)-175-180 | 3.5″ Discharge / PF thread |
| 1HP*4″ | L2F4-165-190 | 4″ Discharge / PF thread | |
| HCP L-62A | 2HP*6″ | 6″ Female thread | |
| HCP L-63A | 3HP*6″ | 6″ Female thread | |
| HCP L-200A | 7.5HP*8″ | Including : LOP8 | |
| HCP L-250A | 10HP*10″ | Including : LOP10 | |
| HCP L-300A | 15HP*10″ | Including : LOP10(12) | |
| 15HP*12″ | Including : LOP12 | ||
※The LOP PVC Pipe is a regular accessory and it is built in L-200A, L-250A and L-300A.
IP6 PVC Pipe is optional accessory for purchase for L-62A and L-63A.
Lower Flange and Double Flange are optional accessories for purchase for IC-32B/33B/43B/45B, L-405A and L-41A.
Hose Connection, Thread Connection, Flange Connection and Double Flange Set are optional accessories for purchase for IC-48, IC-68, IC-410 and IC-610.
