| Model | Lifting Capacity (top layer) | Lifting Speed m/min | Motor Output 110V kw x A | Motor Output 220-240V kw x A | Braking Methods For gear | Brake | Lifting Height m | Wire Rope Φ mm×m | Percentage Duty Cycle |
| CHIYEAH SK-80 | 80 Kg | 18 ~ 30 | 0.8 x 9 | 0.8 x 5 | series wound | mechanical ratchet | 29 | 4 x 30 | 25% ED |
| CHIYEAH SK-160 | 160 Kg | 15~22 | 1.2 x 12 | 1.2 x 6 | series wound | mechanical ratchet | 29 | 5 x 30 | 25% ED |
| CHIYEAH SK-195 | 195 Kg | 12~18 | 1.25 x 12 | 1.25 x 6 | series wound | mechanical ratchet | 29 | 5 x 30 | 25% ED |
| CHIYEAH SK-230 | 230 Kg | 9~14 | 1.3 x 13 | 1.3 x 6.5 | series wound | mechanical ratchet | 29 | 5 x 30 | 25% ED |
Winches are not to be used for the moving of persons
Each new winch is guaranteed against defects in workmanship and material defects for a period of twelve months from date of purchase
| Model | STANDARD ACCESSORIES | PACKAGE |
| CHIYEAH SK-80 | – 4 mm x 30 m wire rope and hook K-10 – Pendant control K160A |
– Winch Weight : 10 kg – Gross Weight : 19 kg – Box Dimension : 500 x 250 x360 mm |
| CHIYEAH SK-160 | – 5 mm x 30 m wire rope and hook K-10 – Pendant control K160A |
– Winch Weight : 17 kg – Gross Weight : 24 kg – Box Dimension : 500 x 250 x360 mm |
| CHIYEAH SK-195 | – 5 mm x 30 m wire rope and hook K-10 – Pendant control K160A |
– Winch Weight : 17 kg – Gross Weight : 24 kg – Box Dimension : 500 x 250 x360 mm |
| CHIYEAH SK-230 | – 5 mm x 30 m wire rope and hook K-10 Pendant control K160A | – Winch Weight : 17 kg – Gross Weight : 24 kg – Box Dimension : 500 x 250 x360 mm |
