Hooks that prevent lateral shifting
– These hooks are designed to prevent the load from coming off or shifting sideways.
Coated hand chains that are highly resistant to rust and corrosion
– A special coating on the hand chains used for operation prevents rust and corrosion and keeps the operator’s hands clean.
Load chains that boast a strength of 1,000 N/mm2
– Sporting superb wear-resistance and durability, these high-strength chains can withstand use in heavy-duty environments over extensive periods of time.
Asbestos-free brake lining
-Asbestos-free, environmentally friendly materials are used for brake lining.
Dual-pawl brakes
– The dual-pawl construction ensures greater safety: should one break, the other continues to support the load.
| Item no. | Rated load (t) | Standard lift (m) | Hand chain length n (m) | Test load (t) | Load chain | Min. | |
| Diameter (mm) | No. of falls | headroom (mm) | |||||
| HN10050 | 0.5 | 2.5 | 2.5 | 0.75 | 5 | 1 | 300 |
| HN10100 | 1 | 1.5 | 6.3 | 1 | 368 | ||
| HN10160 | 1.6 | 2.4 | 7.1 | 1 | 405 | ||
| HN10200 | 2 | 3 | 3 | 3 | 7.9 | 1 | 428 |
| HN10320 | 3.2 | 4.8 | 10 | 1 | 505 | ||
| HN10500 | 5 | 7.5 | 10 | 2 | 660 | ||
| Item no. | Pulling effort | Net weight | External dimensions (mm) | |||||
| (N) | (kg) | A | B | C | F | H | I | |
| HN10050 | 243 | 8.8 | 132 | 148 | 85 | 22 | 35 | 15.5 |
| HN10100 | 282 | 11.5 | 153 | 172 | 104 | 27 | 40 | 20.5 |
| HN10160 | 298 | 15.6 | 175 | 197 | 110 | 32.5 | 42.5 | 19 |
| HN10200 | 298 | 19 | 175 | 210 | 118 | 33 | 50 | 27 |
| HN10320 | 426 | 30.5 | 204 | 250 | 128 | 39 | 50 | 24.5 |
| HN10500 | 381 | 40.4 | 188 | 285 | 175 | 46 | 65 | 42 |
