| Specifications | COME UP Rhino 8 | COME UP Rhino 12 |
| Part number | PN 850812 (12V) / PN 850824 (24V) | PN 851212 (12V) / PN 851224 (24V) |
| Rated line pull | 3,630 kg / 8,000 lb (SAE J706 rating) | 5,440 kg / 12,000 lb (SAE J706 rating) |
| 3,560 kg (EN 14492-1 rating) | 5,100 kg (EN 14492-1 rating) | |
| Motor | 3,430 w / 4.6 hp 12V series wound | 4,180 w / 5.6 hp 12V series wound |
| 1,940 w / 2.6 hp 24V series wound | 2,690 w / 3.6 hp 24V series wound | |
| Gear train | 3-stage planetary 211:1 | 3-stage planetary 315:1 |
| Winch construction | Aluminum die cast housings with steel drum | Aluminum die cast housings with steel drum |
| Clutch (Freespooling) | Rotating ring gear | Rotating ring gear |
| Brake (outside the drum) | Automatic, full load CBS (Cone Brake Structure) | Automatic, full load CBS (Cone Brake Structure) |
| Rotation of winch | Wire rope shall be under-wound orientation only | Wire rope shall be under-wound orientation only |
| Drum size | 90 x 205 mm (3.5” x 8.1″) | 114 x 195.5 mm (4.5” x 7.7″) |
| Control | Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord | Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord |
| Mounting bolts pattern | 254 x 114 mm (10” x 4.5”) | 254 x 114 mm (10” x 4.5”) |
| 254 x 165 mm (10″ x 6.5″) | 254 x 165 mm (10″ x 6.5″) | |
| Wire rope recommended | * 10 mm x 22.6 m, 1,960 N/mm2 grade with a minimum breaking strength of 69.8 kN required for EN 14492-1 rating. | * 12 mm x 21.4 m, 1,960 N/mm2 grade with a minimum breaking strength of 100.5 kN required for EN 14492-1 rating. |
| * 3/8″ x 100′, EIPS grade with a minimum breaking strength of 15,663 lbf required for SAE J706 rating | * 1/2″ x 100′, EIPS grade with a minimum breaking strength of 22,552 lbf required for SAE J706 rating | |
| Winch weight (including rope) | 31 kg / 68.3 lb | 47 kg / 104 lb |
| Gross weight | 47 kg / 104 lb | 61 kg / 134 lb |
| Box dimension, (L x D x H) | 650 x 260 x 440 mm (25.6″ x 10.2″ x 17.3″) | 695 x 313 x 473 mm ( 27.3″ x 12.3″ x 18.6″) |
