| Item no. | Rated load (t) | Standard lift (m) | Hoisting speed | Motor output (kW) | Motor insulation class | Rated time (min) | ||||
| 50Hz | 60Hz | |||||||||
| (m/sec) | (m/min) | (m/sec) | (m/min) | 50Hz | 60Hz | |||||
| MHP5005 | 0.5 | 4 | 0.143 | 8.6 | 0.167 | 10 | 0.83 | 1 | B | 30 |
| MHP5010 | 1 | 0.103 | 6.2 | 0.122 | 7.3 | 1.17 | 1.4 | |||
| MHP5020 | 2 | 0.112 | 6.7 | 0.132 | 7.9 | 2.5 | 3 | |||
| MHP5030 | 3 | 0.073 | 4.4 | 0.087 | 5.2 | |||||
| MHP5050 | 5 | 0.043 | 2.6 | 0.052 | 3.1 | |||||
| Item no. | Rated load (t) | Load chain | Power cable length (m) | Push-button switch cord length S (m) | Test load (t) | Traversing rail width b (mm) | Min. curve radius (m) | Min. headroom G (mm) | |
| Diameter | No. of falls | ||||||||
| MHP5005 | 0.5 | 7.1 | 1 | 5 | 3.6 | 0.625 | 75,100,125 | 1 | 515 |
| MHP5010 | 1 | 1.25 | 525 | ||||||
| MHP5020 | 2 | 11.2 | 3.8 | 2.5 | 100,125,150 | 1.2 | 710 | ||
| MHP5030 | 3 | 3.75 | 1.5 | 770 | |||||
| MHP5050 | 5 | 2 | 6.25 | 125,150,175 | 955 | ||||
