| Model | Lifting Load kg | Speed m / min | tor Output 110V kw x A | Motor Output 220-240V kw x A | Motor Type | Braking Methods For motor | Braking Methods For gear | Maximum Lifting Height m | Wire Rope Φ mm×m | Drum Barrel Diameter | Drum Flange Diameter | Distance between Flanges | Percentage Duty Cycle |
| CHIYEAH KIO-201 | 200 Kg | 11~16 | 1.2 X 12 | 1.2 x 6 | series wound | Electromagnetic brake | Mechanical brake | 70 | 5 x 71 | 95 mm | 190 mm | 147 mm | 25% ED |
| CHIYEAH KIO-301 | 300 Kg | 16~25 | 2.3 X 11 | series wound | Electromagnetic brake | Mechanical brake | 39 | 7 x 40 | 95 mm | 190 mm | 147 mm | 25% ED |
Note：Above performance ratings are based on 50 Hz supply. (60 Hz motor available as option resulting in a reduction of lifting capacities by 20% and a speed increase of 20%)
1. All ratings are based on the top layer. For each layer reduction on the drum pulling capacity is increased by 10%
2. Use a snatch block for double line operation、to increase line pull by approximately 85%
| PULLING LOAD CAPACITY FOR VARIOUS INCLINES in kg | |
| Gradient%inclines / Angle in degrees | Pulling capacity (kg) |
| Level Surface | 1,500 |
| 10% / 60 | 800 |
| 20% / 110 | 600 |
| 40% / 250 | 400 |
| 60% / 310 | 325 |
| 80% / 390 | 270 |
A gradient of 10% is a rise of one meter in ten meters The pulling capacities are based on a free pulling load and 15% has been allowed for friction (specific applications will vary)
Winches are not to be used for the moving of persons
Each new winch is guaranteed against defects in workmanship and material defects for a period of twelve months from date of purchase
| Model | A | B | C | D | E | F | G | H | I |
| CHIYEAH KIO-201 | 205 | 270 | 94 | 135 | 560 | 156 | 93 | 195 | 205 |
| Model | A | B | C | D | E | F | G | H | I |
| CHIYEAH KIO-301 | 205 | 270 | 94 | 135 | 600 | 156 | 93 | 195 | 205 |
‧Remote control K-613A assembly
| Model | STANDARD ACCESSORIES | PACKAGE |
| CHIYEAH KIO-201 | – 5 mm x 71 m wire rope – Weight hook K-15 – Pendant Switch K613 – Switch cord 1.25 mm x 6C X 10 m – Power lead 1.5 mm x 3C X 3m and industry plug |
– 33 kg – 35 kg – 545 x 395 x350 mm |
| CHIYEAH KIO-301 | – 7 mm x 25 m wire rope – Pendant Switch K-613 – Switch cord 2 mm x 6C X 6 m – Remote control K-613A assembly |
– 40 kg – 42 kg – 630 x 395 x350 mm |
