Part number |
PN 859312 (12V) |
Rated line pull |
4,082 kg / 9,000 lb single line |
Motor |
3,430 w / 4.6 hp 12V series wound |
Gear ratio |
3-stage planetary 156:1 |
Clutch (freespooling) |
Rotating ring gear for manual rope unwinding |
Brake (outside the drum) |
Automatic, full load CBS (Cone Brake Structure) |
Winch construction |
Aluminum die cast housings with steel drum |
Drum size: |
63.5 x 125 mm (2.5” x 4.9”) |
Control |
Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord |
Rope type |
Synthetic rope |
Rope size |
10 mm x 15.2 m (3/8” x 50’) |
Mounting bolts pattern |
152 x 114 mm (6” x 4.5”) |
Winch weight (including rope) |
24.5 kg / 54 lb |
Gross weight |
34.3 kg / 75.6 lb |
Box dimension, (L x D x H) |
550 x 195 x 425 mm (21.7″ x 7.7″ x 16.7″) |
