| Part number |
COME UP PN 296155 |
COME UP PN 296060 |
COME UP PN 296088 |
| Rated line pull |
3,630 kg / 8,000 lb single line |
3,630 kg / 8,000 lb single line |
3,630 kg / 8,000 lb single line |
| Motor |
5,250 w / 7.0 hp 12V series wound |
5,250 w / 7.0 hp 12V series wound |
5,250 w / 7.0 hp 12V series wound |
| Gear ratio |
3-stage planetary 67:1 |
3-stage planetary 67:1 |
3-stage planetary 67:1 |
| Clutch (freespooling) |
Rotating ring gear |
Rotating ring gear |
Rotating ring gear |
| Brake (outside the drum) |
Automatic, full load CBS (Cone Brake Structure) |
Automatic, full load CBS (Cone Brake Structure) |
Automatic, full load CBS (Cone Brake Structure) |
| Winch construction |
Aluminum die cast housings with steel drum |
Aluminum die cast housings with steel drum |
Aluminum die cast housings with steel drum |
| Drum size: |
63.5 x 176.2 mm (2.5” x 6.9”) |
63.5 x 227 mm (2.5” x 8.9”) |
63.5 x 125.4 mm (2.5” x 4.9”) |
| Control |
Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord |
Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord |
Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord |
| Recommended battery |
650 CCA minimum for winching |
650 CCA minimum for winching |
650 CCA minimum for winching |
| Battery lead |
1.8 m (6′) 2 gauge battery lead |
1.8 m (6′) 2 gauge battery lead |
1.8 m (6′) 2 gauge battery lead |
| Mounting bolts pattern |
203.2 x 114 mm (8.0” x 4.5”) |
254 x 114 mm (10” x 4.5”) |
152.4 x 114 mm (6.0” x 4.5”) |
| Mounting |
Foot forward or foot down mounting workable |
Foot forward or foot down mounting workable |
Foot forward or foot down mounting workable |
| Finish |
Matte black powder-coated |
Matte black powder-coated |
Matte black powder-coated |
| Winch weight (including rope) |
27 kg / 59.5 lb |
28 kg / 61.7 lb |
26 kg / 57.3 lb |
| Gross weight |
39.5 kg / 87 lb |
40.5 kg / 89.1 lb |
38.5 kg / 85 lb |
| Box dimension, (L x D x H) |
683 x 209 x 430 mm (26.9″ x 8.2″ x 16.9″) |
712 x 209 x 430 mm (28″ x 8.2″ x 16.9″) |
653 x 209 x 430 mm (25.7″ x 8.2″ x 16.9″) |
